Advanced Networking Solution Designed for Secure and Stable Connectivity
The Ruijie Reyee RG-EG210G-P-V3 is a powerful cloud-managed router tailored for SMBs, hotels, schools, and commercial networks. Equipped with 10 Gigabit Ethernet ports—8 of which support PoE/PoE+ with a 110W power budget—it ensures reliable power and connectivity for IP phones, access points, and surveillance. It supports up to 4 WAN ports with intelligent load balancing and failover, making internet connectivity seamless. With integrated VPN, SD-WAN, captive portal, application control, and free lifetime Ruijie Cloud management, this unit delivers enterprise-grade performance in a compact, fanless design.
Key Features
- 10 Gigabit Ethernet Ports: Includes 8 PoE/PoE+ ports delivering up to 110W for powering network devices directly.
- Multi-WAN Load Balancing: Supports 4 WAN ports with seamless failover and bandwidth aggregation.
- Free Cloud Management: Enables full configuration and monitoring via Ruijie Cloud platform at no cost.
- Power over Ethernet (PoE+): IEEE802.3af/at compliant with 30W per port output, ideal for IP cameras and wireless APs.
- Comprehensive VPN Support: Supports IPSec, OpenVPN, PPTP, L2TP with up to 100 concurrent accounts.
- Integrated SD-WAN: Supports 24 SD-WAN tunnels with up to 8 branches for simplified branch networking.
- Captive Portal and Authentication: Includes local and Ruijie Cloud-based portals, RADIUS support, and voucher authentication.
- Application Management: Features app block, identification, and smart flow control with automatic rule updates.
- Security and Firewall: Equipped with ACLs, DoS protection, MAC filtering, IP-MAC binding, and security zones.
- Fanless and Compact Design: Passive cooling ensures silent operation, perfect for office environments.
- High Concurrent Capacity: Supports up to 200 concurrent clients and 60,000 sessions for demanding networks.
- Advanced Routing and NAT: Includes static routing, RIP, OSPF, NAPT, NAT ALG, and multi-WAN IP-based routing.
- Extensive Device Management: Manages up to 150 devices in router mode and 500 in AC mode.
A robust and scalable solution ideal for organisations needing secure, managed, and PoE-capable network infrastructure.
| Product Specifications | |
|---|---|
| Ethernet Ports | 10 x 10/100/1000BASE-T |
| PoE Support | 8 ports (IEEE802.3af/at), 110W total |
| WAN Ports | 4 |
| LAN Ports | 9 |
| Concurrent Clients | 200 |
| Max Concurrent Sessions | 60,000 |
| VPN Protocols | IPSec, OpenVPN, L2TP, PPTP |
| Max VPN Accounts | 100 |
| SD-WAN | 24 tunnels, 8 branches |
| Cloud Management | Ruijie Cloud, lifetime free |
| Authentication Methods | RADIUS, voucher, portal, 802.1X |
| Firewall | ACLs, DoS protection, MAC filtering |
| Power Supply | 54V DC, 2.4A (AC input: 100–240V) |
| Power Consumption | <130W |
| Dimensions | 202 x 108 x 28 mm |
| Net Weight | 1.48 kg |
| Cooling | Fanless, natural convection |
| Mounting | Desk-type |
| Operating Temperature | 0~40°C |
| Storage Temperature | -40~70°C |
